Pop Rivets Peeled Series from 3210 – 4835 (Packs of 100)

Description

Peeled Pop Rivets (PAS Series: 3.2 × 10 to 4.8 × 35, Packs of 100)

Product Overview

Material Composition

• Body: Aluminum (commonly grade 5056)

• Mandrel: Steel

Design Feature

• The term “peeled” refers to the unique end-of-rivet action: the body splits into multiple petals (typically four) that fold outward on the blind side, creating a broad bearing surface. This enhances grip—especially effective in soft or brittle substrates such as plastics, laminates, wood, and rubber.

---

Sizes & Specifications

Typically offered from 3.2 mm × 10 mm through 4.8 mm × 35 mm, these rivets accommodate a wide grip range, ideal for various material thicknesses.

Common options include:

• 3.2 × 10, 3.2 × 12, 3.2 × 15 (approx. grip ranges from ~2–9 mm)

• 4.8 × 12, 4.8 × 15, up to 4.8 × 35 (grip up to ~27 mm)

• 3.2 × 10 mm — Head dia ≈ 6.35 mm, grip ~2–4 mm, tensile ~720 N, shear ~760 N

• 4.8 × 35 mm — Grip ~24–27 mm .

---

Features & Benefits

• Wide Blind-Side Bearing Surface: The “peeled” petals create a larger footprint, reducing the chance of the rivet pulling through in fragile or soft materials.

• Tolerant of Oversized Holes: The spreading action helps compensate for minor misalignment or larger-than-meant holes.

• Versatile Applications: Commonly used in plastics, plywood, laminates, cardboard, leather, and coated substrates due to its gentle but secure fastening action

• Aesthetic Finish: Leaves a clean, domed appearance on the near-side; the blind side blossoms out neatly for a polished look.

---

Suggested Use Cases

• DIY and light joinery involving soft or delicate panels like furniture, signboards, decorative elements

• Joins between dissimilar materials, e.g., metal to plastic or wood

• Applications requiring blind-side grip without damaging substrate integrity
