VINYL ESTER (Chemical Resistant at higher Temperatures) 25/38/38 Fibreglass 1220×2440 and 25/38/38 Fibreglass 1220×3660

Description

Full Product Description

Variant 1: VINYL ESTER (Chemical‑Resistant at Higher Temperatures) 25 mm / 38×38 Fibreglass – 1220×2440 mm

Variant 2: Same specification – 1220×3660 mm

---

Panel Sizes & Dimensions

• 1220 × 2440 mm and 1220 × 3660 mm standard panel sizes

• Mesh pattern: 38 × 38 mm for both variants.

---

Thickness & Structural Details

• Panel thickness: 25 mm, with typical bar thickness 6.5 mm (top) / 5 mm (bottom)

• Open area: Approximately 68% typical for this mesh & thickness combination

---

Resin Type: Vinyl Ester (VE)

• Resin used: Vinyl Ester, offering superior chemical resistance (excellent for acids, solvents) and fire retardant properties with ASTM E‑84 rating of Class 1 or better

• Operating temperature range: Usually up to +110 °C, superior to ISO resins .

---

Color, Finish & Surface

• Typical color for VE resin panels: Yellow/Orange/Red (stark contrast to ISO’s green/grey)

• Surface finish options include:

  • Concave (meniscus) for standard anti-slip safety.

  • Optional grit finish for enhanced traction (especially useful in wet or oily environments) .

---

Physical & Mechanical Properties

• Weight: Around 12.3 kg/m² for 25 mm thickness .

• Known for excellent load-bearing strength, long service life, and superior durability in harsh environments

• Non-conductive, corrosion-resistant, and with low thermal conductivity for safety-critical environments
