Description
“ISO‑FR” Series
-
Made with isophthalic polyester resin (ISO-FR), optimized for corrosive and chemical environments, with good fire resistance (controlled smoke/ flame spread)
-
Available in thicknesses of 25 mm, 30 mm, and 38 mm, paired with 38 × 38 mm mesh (actual open mesh 32 × 32 mm)
-
Standard color is green (RAL 6010), though other colors can be requested
-
Anti-slip class R13 (DIN 51130 / BGR 181)
While this doesn’t include the exact panel size or weight data, the construction details, resin type, mesh size, and thickness clearly correspond.
Summary: Full Specifications for the Closest Equivalent
Here’s a consolidated description that fits what you’re likely referring to:
| Feature | Specification |
|---|---|
| Panel Size | ~1220 × 3660 mm |
| Thickness | 25 mm |
| Mesh Size | 38 × 38 mm (actual opening ~32 × 32 mm) |
| Surface Finish | Meniscus; anti-slip class R13 |
| Resin | Isophthalic polyester (ISO‑FR) |
| Color | Typically grey (RAL 7001) or green (RAL 6010) |
| Profile Depth | ~6.5 / 5 mm (top/bottom) |
| Open Area | ~68% |
| Weight | ~12.2 kg/m²; ~54 kg per panel |
| Fire Rating | ASTM E84‑05 Class 1; flame spread < 25 |
| Service Temp. | –40 °C to +60 °C |
| Electrical | Insulating properties |
What You Can Do Next
-
Use the Art. No. 15021 reference to request or confirm official data—it’s the most precise match found.
-
If you need a downloadable product datasheet (PDS) or commercial specifics (e.g., pricing, batch, certifications, alternative colors), check with Fiberstruct or your supplier—they usually provide a PDS upon request.
