Description
Key Features
Engine / Drive System
-
No engine on the unit itself – the sweeper is driven by the rear wheel of the towing vehicle.
-
Brushes and sweeping mechanism are powered through a gearbox and chain drive connected to the towing vehicle wheel movement.
Transmission
-
Gearbox with:
-
Neutral position
-
Two operating speeds (approximately 100 RPM and 150 RPM)
-
Neutral universal coupling
-
Heavy-duty chains and sprockets to transfer power from the tow vehicle wheel to the brushes.
-
Sweeping Mechanism
-
Heavy-duty cylindrical brushes designed for robust road debris removal.
-
Manual angle adjustment of the brush up to 30° to either side for effective sweeping direction control.
Build & Durability
-
Robust frame and chassis, fully cleaned and painted (choice of color) for corrosion resistance.
-
Includes an operator platform guard, hood lifting bar, and hood chain guard for safety and easier maintenance access.
Mobility & Attachment
-
Three-wheel chassis design with short turning radius for better maneuverability on site.
-
Easy to attach to a range of vehicles including tractors and LDVs/trucks.
-
Recommended top towing speed while sweeping is up to 8 km/h for safety and optimal sweeping performance.
Applications
-
Wide use in road construction prior to asphalt laying, chipping, lime spreading, crushed rock leveling and general surface cleanup.
-
Helps improve site safety and efficiency by reducing loose debris and preparing surfaces before further works.
Variants
-
RS96B: Similar specification but features a solid steering front wheel and a bolt-on drawbar, along with a height-adjustable landing leg for improved stability when uncoupled.
Typical Specifications (Approximate / Based on Listings)
-
Working Width: ~2.6 m (varies by configuration)
-
Weight: ~998 kg (used unit example)
-
Drive: Wheel-powered via rear tow wheel (no onboard power unit)
Why Choose the RS96 Sweeper
✅ Simple, rugged, and easy to maintain — fewer moving parts than engine-driven models.
✅ Cost-effective — uses existing towing vehicle power instead of a dedicated engine.
✅ Versatile for construction and municipal use — clears debris ahead of paving and material spreading.
