Frameless shower fittings HINGE GLASS TO GLASS 135deg ADJ PC and ADJ PSS

Description

Technical Descriptions

ES2.135 PC — 135° Glass-to‑Glass Hinge, Polished Chrome (Fixed)

• Connects two glass panels at a 135° angle.

• Suitable for 10 mm glass.

• Weight capacity:

  • 35 kg per pair (2 hinges)

  • 52.5 kg per triple set (3 hinges)

• Maximum door width: 800 mm.

• Equipped with hex head machine screws for installation.

• Doors open both inwards and outwards.

• Self-closes from about 30°.

• Made from high-quality brass, ensuring durability.

BES2.135 PC — 135° Bevelled Glass-to‑Glass Hinge, Polished Chrome

• Similar specs to ES2.135 PC, but features a bevelled design for a sleeker aesthetic.

• Supports the same glass thickness, weights, widths, and functions (self-closing, two-way opening).

• Available finishes include Polished Chrome, Satin Chrome
